Customised 300MHz-45.5GHz Waveguide Filters / Waveguide Bandpass Filters
Characteristics and Application
Waveguide filters are characterised by high Q, low insertion loss, wide bandwidth coverage, high power handling capability, high interference immunity, good temperature stability, high customisation capability and size optimisation in terms of performance. The excellent performance of waveguide filters makes waveguide filters play an important role in the field of communication, radar and satellite communication.
Product Principle
Technical Index
| Model | Freq.Range | Insertion loss | VSWR | Stopband rejection | Stopband rejection | Conn.Type | Material | Appearance | Dimension |
| BPF3.95GWN | 3.7-4.2GHz | 1dB | 1.5 | ≥65dB@3.2GHz | ≥65dB@4.4GHz | BJ84flange | Copper/Aluminum | Black paint | 145*100*70mm |
| BPF8.205GWN | 7.91-8.5GHz | 0.3dB | 1.2 | ≥60dB@7.348 | ≥65dB@9.252GHz | BJ84flange | Copper/Aluminum | Black paint | 105*46*35mm |
| BPF11.725GWN | 10.7-12.75GHz | 0.5dB | 1.5 | ≥25dB@9.59GHz | ≥25dB@14GHz | BJ120flange | Copper/Aluminum | Black paint | 75*38*38mm |
| BPF19.45GWN | 17.7-21.21GHz | 0.4dB | 1.3 | ≥20dB@25GHz | BJ220flange | Aluminum | Black paint | 61*23*23mm | |
| BPF30.2GWN | 29.4-31GHz | 0.3dB | 1.3 | ≥30dB@DC-25GHz | BJ320stand flange | Copper | gold-plated | 155*34*20mm | |
| BPF38GWN | 36-40GHz | 1dB | 1.3 | ≥60dB@34.1GHz | ≥60dB@42GHz | BJ320flange | Copper | gold-plated | 49*24*20mm |
| BPF44.5GWN | 43.5-45.5GHz | 2dB | 2 | ≥60dB@42.8GHz | ≥60dB@46.2 | BJ400flange | Copper | gold-plated | 71*13*9mm |
Nots
Technological Strength
After more than a decade of intensive research and development, XST Technology is now at the forefront of the industry and has demonstrated outstanding R&D capabilities. XST has a team of highly skilled and experienced professionals who have been awarded many patents and intellectual property rights in filter technology. We actively cooperate with domestic and foreign universities and research institutes to deepen technical exchanges and promote technological innovation, and we are also active in the industry standard-setting arena, leading the industry wind vane.
Outstanding Performance
XST is a leading manufacturer of microwave components such as filters, especially waveguide filters from 300MHz to 45.5GHz. We are committed to high quality, and each filter is carefully designed and tested to ensure precise and effective performance. Our filters operate over a specified frequency range, with lossless signal passage in the passband and effective attenuation in the stopband, making them ideal for applications such as wireless communications, radar systems and satellite communications.
Superior price/performance ratio
As a leading manufacturer of microwave components, we lead the industry by supplying direct from the source at competitive prices. By combining efficient production with precise cost control, we create high-quality filters at an affordable price. The core of our pricing strategy is to maximise customer value so that every partner can embrace cutting-edge technology in a budget-friendly manner and reap unimaginable value in return.
Customisation Capabilities
XST understands the essence of filter customisation, and we are dedicated to meeting the specific needs of waveguide filters from 300MHz to 45.5GHz. We are able to accurately match every detail of our customers' requirements, from precise bandwidth design to fine tuning of bandwidth, perfect control of insertion loss, return loss, and out-of-band rejection, every step of the way, our team of experts ensures that each filter not only fits the customer's unique scenarios, but also helps to improve operational efficiency and create a new high point of value.
Send in your metrics needs and experience our unrivalled customisation capabilities.
