18GHz -40GHz Band Reject Filters-Specialised In Customised Production Of High Performance Rf Band Reject Filters
Characteristics and Application
18GHz -40GHz filters offer the following advantages:
1. high-frequency performance: capable of handling high-frequency signals up to 40GHz, suitable for high-end applications such as 5G communications, satellite communications, radar systems and so on.
2. high selectivity: provide excellent frequency selectivity, effectively separating the desired signal from interfering signals.
3. low insertion loss: low signal loss to ensure signal strength and quality.
4. high rejection performance: high rejection ability, reduce the impact of interference on system performance.
5. high Q: can provide a narrower bandwidth and better frequency selectivity.
6. temperature stability: suitable for use in variable environmental conditions.
7. wide bandwidth capability: support wider bandwidth to adapt to changing communication needs.
Technical indicators
| Product Name | Bandpass filter |
| Frequency Range | 18GHz -40GHz |
| Insertion loss | ≤1.5dB |
| VSWR | ≤1.8 |
| In-band fluctuation | 1dB |
| Out-of-band rejection5 | ≥30dB@ 17 |
| port connector | 2.92mm-K (one yin and one yang) |
| Size | 80*16.2*10mm |
| Impedance | 50 OHMS |
Nots
Filters to avoid coupling of input and output cables: When wiring, avoid bundling the input and output cables of the filters together to reduce the negative impact of electromagnetic coupling on the performance of the filters.
Maintenance and care of the filter: regular maintenance and inspection of the filter, especially when using electrolytic capacitors, need to pay attention to their life and regular replacement .
Avoid installing filters inside the shielding: installing filters inside the shielding may result in the EMI radiation generated by circuits and components inside the equipment being directly coupled to the outside of the equipment, thus reducing the shielding effect.
Atmospheric and environmental factors: Millimetre wave signals are more sensitive to atmospheric conditions, rainfall, fog and other atmospheric conditions may affect signal propagation and cause some degree of interference or attenuation.
Customer Concerns
Production Capability
XST is a microwave device source factory with 12 years of experience and a complete product line. Product development, manufacturing, and testing are all done in-house, which enables XST not only to effectively improve production efficiency and reduce costs, but also to quickly respond to market demand and ensure product quality. Equipped with state-of-the-art production facilities and cutting-edge equipment, I am able to maintain large-scale production capacity while maintaining a high degree of flexibility, which enables us to quickly adjust our production plan according to market demand and achieve flexible production of multiple varieties and small batches. Product quality is ensured through a strict quality control system, advanced testing equipment and a professional quality inspection team. At the same time, they also focus on continuous improvement of production processes to enhance product quality levels to meet customer demand for high-quality products.
Brand Strength
After 12 years of innovation and development, XST enjoys a high degree of recognition and reputation in the microwave field. The company has 100+ professional microwave talents, 500+ cooperative customers, and long-term cooperation with many research institutes such as Military Research Institute, Aerospace Research Institute, and 5G Technology Research Institute, etc. XST team members not only obtained a number of patented technology certifications in the field of microwave, but also took the lead in passing the ISO9001 quality system certification, as well as the GJB9001B military quality system certification.
High Quality
XST filters are made of advanced technology and high-end materials to ensure that the products are not only beautiful in appearance, but also excellent in durability and functionality. Each filter undergoes a strict quality inspection process, from raw material screening to finished product packaging, each step strives for perfection, excellent quality, making XST filters stand out in a large number of similar products, the quality far exceeds the market average, and has won a number of industry experts and customers unanimously praised the quality of excellence, is our unchanging commitment to build each product with care, so you get the best quality filters in the same price range. We make every product with our heart, so that you can get the best quality filters in the same price range.
Affordable Prices
We understand that true competitiveness lies in providing value and service that exceeds expectations at an affordable price. Compared with similar microwave products, our price advantage is as high as 30%-50%, which is the cost-effective choice. Customer satisfaction is our greatest pursuit, and the most competitive price is one of our secrets to win the reputation. Affordable price, but the quality does not discount, thousands of customers choose us, not only because we offer the market irresistible price, but also because of the excellence of our products, the high praise of many customers, the common witness to the excellence of our quality. Affordable prices and excellent quality are accompanied by worry-free after-sales service.
By choosing us, you are choosing the experience of both cost-effectiveness and peace of mind.
XST is your direct choice for cost-effectiveness and peace of mind.
